How can we identity the number of PCB layers? It is something relates to our quotation, our production process, the lamination and and final quality. It is one of the basic skills that we need to handle. Here are some methods for you to use to count the number of layers as below:
The First. Visual Inspection, a most intuitive way, just using our eye to check the quantity of insulation between the layers which is using to ensure that there will be no shorrrt circuit issue between different PCB layers , that we can consult the layer quantity .
The Second methods we can identity the number of PCB layers is the“via” on the PCB to identify the number of PCB layers. The principle is mainly due to the use of via technology for the circuit connection of multilayer PCBs in many PCB factory in Shenzhen, china .
For example, if some of the board guide holes appear on the front side of the PCB board, but found on the reverse side. Then it is a 6/8 layer board. If we can find the same guide hole on both sides of the PCB board. It is naturally a 4-layer board.
Or other is involves in blind holes ,since the blind holes do not need to run through the entire PCB, if it is six or more layers, the board will be viewed from the light source, and the light will not pass through. So there is also a very popular saying before. We usually use the vias leak light to judge the PCB is four or more layers of PCBs.
And the last one is accumulation method, to be exact , this is not a method , but an experience , which should be the most accurate one .We can judge by the routing of the common PCB board and the position of the components.
Do you have any other methods to identity the number of PCB layer ? Hey, please share it with us.
